Upper Groove Mount Square Gas Spring Plate

This upper groove mount square gas spring plate is used in injection molded or fabricated assemblies where a gas spring must be positioned with repeatable alignment. It is typically integrated into cabinet lift mechanisms and access panels by attaching a compatible bracket plate that presents an upper groove interface for the actuator.

Two common scenarios include:

• Automotive and industrial access covers: pairing the plate with the correct actuator model helps maintain consistent stroke alignment under vibration and cyclic loads.
• Appliance and furniture lift systems: the square plate footprint supports stable mounting while the upper groove connection simplifies repeatable installation across product variants.
• Serviceable enclosure design: using plates only allows engineers to swap the plate type (FCQ or FCQB) while keeping the overall gas spring selection aligned to the catalog compatibility table.

The FCQ/FCQB variant selection and wide outer diameter range (D 32–195 mm) make it suited for matching different gas spring sizes used across a family of molded assemblies.

Material, steel grade, hardness, and heat treatment details are not provided in the supplied product data. Because this part is a dedicated mounting plate (plates only) for gas spring systems, its performance is mainly governed by correct dimensional matching to the selected actuator model and plate type (FCQ/FCQB), rather than by a specific metallurgical specification in this dataset.

• Heat treatment: not specified (no information on quenched & tempered, nitriding, or similar processes).
• Hardness / wear resistance vs. toughness trade-off: not specified (no HRC values or abrasion/wear requirements stated).

If you can share the material/grade or the catalog’s steel specification for series 110100263550, we can map it to a comparable standard (e.g., H13-equivalent) and add the requested hardness and treatment details.

To select the correct plate for your gas spring tooling or assembly, match the plate’s outer diameter (D) to the actuator sizing requirements from the catalog compatibility table referenced in the product description. This series supports D 32–195 mm, so choose the value that falls within your required groove/seat envelope.

Selection steps:

• Step 1: Identify the required gas spring model and the compatible plate type from the compatibility table.
• Step 2: Select the plate type as FCQ or FCQB to ensure interface compatibility with the actuator’s upper groove mounting system.
• Step 3: Confirm the plate’s outer diameter is within 32–195 mm for proper fit and mounting clearances on the surrounding bracket structure.

Tolerance and fit: the dataset does not list dimensional tolerances, so ensure your CAD/mold mounting interface provides adequate clearance for assembly variation while maintaining stable seating on the groove interface.
